BOD Incubators Manufacturer, Exporter, Dealer, Supplier

BOD Incubators – Helps Determine Biochemical Oxygen Demand Measure With Highest Accuracy

The BOD incubator is used to store items in an isolated chamber that has a temperature maintained at 20 degrees Celsius. This equipment is needed in arenas such as bacteria culture examination, insect study, germination research, etc. This particular machine is needed in a testing environment where certain products can be checked only when they are maintained at a particular temperature. By putting the items that have to be tested into these BOD incubators, they are well-maintained and, as a result, can be accurately tested. Some of the many places that make use of this equipment include:

  •  Pharmaceutical industry
  •  Beverage manufacturing factories
  •  Research laboratories

    • BOD Incubators Features And Uses

    BOD Incubators, which stands for Biochemical Oxygen Demand Incubators, is a measure of the microbe’s ability to deplete the oxygen content. The BOD incubator is used for the purpose of deriving this measure based on which various conclusions can be reached.

    One of the key arenas where this instrument proves to be useful is testing of pollutants in water. When this instrument is used to test a sample taken from a river or stream that might be polluted, it helps ascertain the amount of contaminants in the water. Low BOD indicates that the water quality is good, whereas high BOD shows that it is highly polluted. Other important arenas where it is used for measurement purposes include:

  •  How much of bacteria has been removed by waste treatment systems.
  •  How such oxygen is used during a particular incubation period for organic material biochemical degradation
  •  How much oxygen is need for the purpose of oxidize an inorganic material
  •  How much oxygen is needed to oxidize nitrogen in its reduced forms

    • Features of our BOD Incubators include:

  •  Plexi glass door through which the sample can be viewed
  •  Inner chamber is lit up by Fluorescent light
  •  Digital LED for temperature display
  •  Castor wheel in theft for easy movement
  •  Steel heater inside with fins
  •  Power supply is through 230 volts 50 Hz main supply.
  •  Temperature Range is +5 °C to 60 °C

    • When a test has to be done, the sample is put into an airtight bottle, which is then placed inside the BOD incubator for a period of time. The DO or Dissolved Oxygen in the sample is measured before and after incubation and the difference between the before and after value is determined as the BOD.


    CONSTRUCTION
    MODEL MATERIAL OF CONSTRUCTION ORDER CODE
    STD Inner SS-304 & Outer GI Powder Coated HCI - STD
    FULL S.S Inner SS-304 & Outer SS-304 Matt finish HECT – SS
    cGMP Inner SS-316 & Outer SS-304 Matt finish, Unit Rested ON SS Pipe Frame Structure and Fitted With SS Castor Wheel HCI - G

    Features

  •  1. Full length inner plexi-glass door for viewing sample.
  •  2. Chamber Illumination: Fluorescent light with door switch
  •  3. Feet: Castor wheel for easy movability.
  •  4. Trays: SS Wire Mesh
  •  5. Temperature Display: Digital LED, 3½ digits
  •  6. Heating: S. Steel Tubular Heater with fins.
  •  7. Consisting of self illuminated mains ON / OFF Switch, Indicating Lamps, Electronics Digital Temp. Controller-cum-indicator and fuse.

    • Power supply

  • 230 volts 50 Hz main supply. Also available with 60 Hz Cycle.

    • Specification
    Temperature Range +5°C to 60°C
    Temperature Accuracy ± 0.5°C
    Temperature Uniformity ± 1°C

    Selection Guide

    Cap Cft/Ltr Dimension (WXDXH) in CM No Of Tray W X D 3.5 cm H Servo Stabilizer & UPS Power Rating
    HCI Internal External Size -CM KVA KW
    3 / 90v 40 X 40 X 57 55 X 88 X 135 2 32 x238 3 1.2
    6 /170 50 X 50 X 70 65 X 100 X 148 2 42 x 48 3 1.2
    8/200 60 X 60 X 60 65 X 100 X 158 2 52 x 58 3 1.2
    10 /285 57 X 57 X 88 72 X 107 X 174 3 49 x55 4 1.6
    12 / 340 60 X 60 X 95 75 X 110 X 181 3 52 x 58 4 1.6
    16 / 450 70 X 70 X 90 85 X 120 X 176 3 62 x 68 5 2.0
    21 / 600 80 X 75 X 100 95 X 125 X 186 3 72 x 73 5/7** 2.0
    28 / 800 80 X 80 X 125 95 X 130 X 200 3 72 x 78 7/7.5** 3.5
    36/1000 90 x 90 x 125 105 X 140 X 200 5 82 x 85 7/7.5** 3.5
    54/1500
    72/2000
    87/2500
    107/3000

    Documents

  •  1. Calibration certificate for controller & Sensor certificate.
  •  2. DQ, IQ, OQ & PQ protocol documents provided with equipment.

    • Optional Accessories

  •  1. Time proportional ON / OFF Controller cum Indicator
  •  2. Micro controller based PID controller cum Indicator
  •  3. mp Controller with Printer Interface
  •  4. mp Controller Interface through RS 232 C / RS 485 for multiple networking
  •  5. Audio/Visual alarms for deviations
