Laboratory Oven, Lab Ovens Manufacturer, Exporter, Dealer, Supplier

Our Laboratory Ovens come with robust structure and state-of-the-art features by which they can be used to carry out heating and drying activities in research centers, forensic labratories and clinics with highest efficiency.

The structure comes with a double-walled, stainless steel outer body, which makes it strong and long-lasting. No matter how heavily this equipment is used, it will show desired performance time and again and will not have any wear and tear issues. It's adjustable mesh or perforated trays can be used for a large number of items and can also be removed or adjusted to accommodate the size of the item to be placed inside.

Laboratory Ovens Uses

Our laboratory ovens can be used to carry out activities such as polymide baking, drying, sterilizing, die-bond curing, dehydrating, annealing, conditioning and evaporating. They are of vital imprtance in activities such as material testing, determining the resilience of a manufactured product, finding out tensile strength, solder strength.

Laboratory Ovens Features

HMG India’s laboratory ovens can operate at temperature that raises upto 200°C and as you can see it is specifically designed to be rugged for laboratory requirements. As it is highly energy efficient, even continuous and constant usage will not result in high utility bills. It also comes with over-temperature and excess current protection, by which such situations are automatically controlled as they arise, thus making way for smooth operations. Its strong double-walled construction is made of stainless steel so it can be reliably used in difficult and rugged environments.

Inside is a motorized blower that helps to maintain uniformity of temperature inside the chamber. The air is blown from bottom to top as the air gets evenly circulated inside, you will find the oven to reach maximum temperature in just one and half hours after initiation. With a temperature accuracy that is ± 1° C, you can be sure of getting high quality performance, one that will be shown repeatedly time and again. With microprocessor controls in place, this equipment will perform according to set specifications, enabling you to get desired output quickly,

One of the key areas of concern with regards to a laboratory oven is if it will be able to retain the heat generated inside accurately. In our models, you can be rest assured of effective thermal insulation as they are filled with inner and outer wall gaps are fitted with insulators that keep external air outside. With an ergonomic design, it can be opened with ease and its shelves can also be removed quickly for cleaning and maintenance.

HMG LABORATORY OVEN - STD Model - 101 SS

Inner Size Watts Cap./Ltrs Tray
inch cm
a 12 x 12 x 12 30 x30 x 30 750 27 1
b 14 x 14 x 14 35 x 35 x 35 750 40 2
c 18 x 18 x 18 45 x 45 x 45 1500 90 2
d 18 x 18 x 24 45 x 45 x 60 2000 120 2
e 24 x 24 x 24 60 x 60 x 60 2500 200 3
f 24 x 24 x 36 60 x 60 x 90 3000 325 3

HMG LABORATORY OVEN - STD Model - 101 SS

OPTIONAL
a) Safety control � against over shoot of temp.
b) Motorized blower, blowing in air from bottom
d) Hi & Low Audio Visual alarm
e) Soak timer controller with end cycle buzzer
f) Soak timer controller with end cycle buzzer (Timer restart from left out time)
Calibration Certificate for controller & sensor with traceability certificate
Protocol documents (if required )
